Description
-
Agilent 5500 Atomic Force Microscope for surface imaging at the nanometer scale. Acquired around 2004, NSF DMR-MRI grant in 2005 – purchased/installed 2006 (-scb). NSF DMR-0520789 from the Division of Materials Research Funded at $217,442
- Nanosurf FlexAFM Microscope for surface imaging below the nanometer scale. This microscope was purchased in 2022 and acquired/installed in 2023.
Capabilities of Microscope
-
Agilent 5500 Atomic Force Microscope: The instrument is for surface imaging at the nanometer scale. It can do contact and non-contact modes.
- Nanosurf FlexAFM Microscope: The instrument is for measuring a materials surface topology with atomic resolution. This particular microscope is capable of high resolution (on the order of a fraction of a nanometer) non-optical imaging which is 1000 times more powerful than optical microscopes. This allows for quantifying the surface roughness below the nanometer scale.
Technical Description
-
The sample is loaded into the instrument beneath the scanner that holds the AFM probe. The probe has a cantilever and tip on it. The instrument software slowly guides the placement of the tip and gently puts it in contact with the sample surface. A laser reflects off the cantilever and hits the detector to generate the image as the tip moves over the surface of the sample.
Service Fees
-
Agilent 5500 Atomic Force Microscope:
-
Students no charge.
-
No customer samples for this instrument. However, our 2016 price was $250/sample.
-
Please contact Pauline Norris (hackpr@wku.edu) for more information about pricing and the Agilent 5500 Microscope.
-
Nanosurf FlexAFM Microscope:
-
Students no charge.
- No customer samples for this instrument. However, our 2016 price was $250/sample.
-
Please contact Dr. Ali Er (ali.er@wku.edu) for more information about pricing and the Nanosurf FlexAFM Microscope.
AFM Agilent 5500 Microscope Contact
AFM Nanosurf FlexAFM Contact
